  • High quality SMA to SMA Straight Adapter up to 26.5Ghz 50ohm

    • High quality SMA to SMA Straight Adapter up to 26.5Ghz 50ohm

    SMA series adapter
    Frequency up to 26.5GHz
    Factory supply with fast delivery
    Welcome to send inquiry

    Inquire Now
    • Product Description

    Adapters SMA

    SMA Precision coaxial connector for microwave applications.the maximum frequency is

    26.5GHz.

    • Design in accordance with: MIL-STD-348

    Standard materials and finish

    • Center conductor:beryllium copper,gold plated

    • Insulator:PTFE

    • Outer conductor:Stainless steel,Passivated

    Electrical Characteristics

    • Characteristic Impedance:50Ω

    • Frequency range:DC-26.5GHz

    • VSWR: DC-18GHz,1.10:1 max

    18-26.5GHz,1.15:1 max

    • Insulation resistance: 5000MΩ min

    • Test voltage:1000V

    Mechanical

    • Coupling torque:1.69N•m max

    • Mating cycles: 1000cycles min

    Environmental

    • Temperature range: -55℃～+155℃

    High quality SMA to SMA Straight Adapter up to 26.5Ghz 50ohm


    Tags: SMA to SMA adapter, SMA adapter 26.5Ghz
